FULDA

FULDA

Isıtma borularının dizilimi şık bir değişim sağlar.
Evrensel kusursuz yetenek açık ifadeyi canlı vurgularla birleştiriyor.

Model özeti

These high quality design radiators are made in Austria. The design radiators manufactured by VOGEL&NOOT meet numerous internationally recognised quality standards and the manufacturing processes at all of the production sites have been ISO certified

Dimensions and models:



FULDA overview of models



Width Uzunluk 500, 600, 750, 900
 Yükseklik 758 1220 1766



 Connections  Connections: 2 x internal thread G 1/2, and 1 x internal thread G 1/4 (for vent plug)

 Test positive pressure  Test overpressure: 13 bar

 Maximal positive operating pressure  Max. positive operating pressure: 10 bar

 Maximal operating temperature  Max. operating temperature: 110 °C

Teknik bilgiler

Bağlantı modları

FULDA connection examples

Flow Flow

Connections  Connections: 2 x internal thread G 1/2, and 1 x internal thread G 1/4 (for vent plug)

Return Return

Test positive pressure  Test overpressure: 13 bar

Vent plug Vent plug

Maximal positive operating pressure  Max. positive operating pressure: 10 bar

Electric connection  Electric connection

Maximal operating temperature  Max. operating temperature: 110 °C

Ebatlar [mm]

FULDA dimensions
